UP50W11M012SBK1Z1NB前面板安装插头Fischer Connectors

发布时间：2024-05-10 09:54:03 浏览：736

　　UP50W11M012SBK1Z1NB是Fischer Connectors公司的一款前面板安装插头，它属于UP50系列。这款插头具有12个触点，设计用于低压信号/电源的传输。它采用面板前置的安装方式，并且外壳由黄铜制成，具有无烟煤哑光的颜色。此外，它还采用了PBT型绝缘材料。在性能方面，该插头具有IP68防护等级，提供了出色的防水防尘能力。此外，它还属于UltiMate系列，并且具有11的系列尺寸。

相关型号：

Connector	Contacts	Termination type	Locking system	Signal / Power	Sealing level
UP50W11 M012S BK1 Z1NB 138845	12	Solder	dependent	Low Voltage	IP68
UP50W11 M019S BK1 Z1NB 137544	19	Solder	dependent	Low Voltage	IP68
UP50W11 M012P BK1 Z1NB 142497	12	PCB	Plug dependent	Low Voltage	IP68
UP50W07 M010S BK1 Z2NB 125230	10	Solder	Plug dependent	Iow Voltage	IP68
UP50N07 M010P BK1Z2NB 134009	10	PCB	Plug dependent	Low Voltage	IP50
UP50W07 M004S BK1 Z2NB 131299	4	Solder	Plug dependent	Low Voltage	IP68
UP50W07 F009S BK1 Z2NB 124446	9	Solder	Plug dependent	Low Voltage	IP68
UP50W11 M008S BK1Z1NB 135391	8	Solder	Plug dependent	Low Voltage	IP68
UP50W07 M007S BK1Z2NB 125240	7	Solder	Plug dependen	Low Voltage	IP68
UP50W11 M016S BK1Z1NB 125543	16	Solder	Plug dependent	Low Voltage	IP68
UP50V07 M004P BK1Z2NB 134821	4	PCB	Plug dependent	Low Voltage	Hermetic
UP50W07 M010P BK1 Z2NB 132195	10	PCB	Plug dependent	Low Voltage	IP68
UP50W07 F009P BK1Z2NB 129112	9	PCB	Plug dependent	Low Voltage	IP68
UP50W07 M009S BK1Z2NB 124442	9	Solder	Plug dependent	Low Voltage	IP68
UP50W07 M007P BK1 Z2NB 128526	7	PCB	Plug dependent	Low Voltage	IP68
UP50W07 M009P BK1Z2NB 124443	9	PCB	Plug dependent	Low Voltage	IP68
UP50W07 M003S BK1Z2NB 130465	3	Solder	Plug dependent	Low Voltage	IP68

相关推荐：

Fischer全系列圆形连接器

更多Fischer连接器相关产品信息可咨询利来国国际网站创展。
